Ansys nCode DesignLife
기본교육

소개

본 교육은 Ansys workbench platform과 nCode DesignLife를 활용하여, 피로해석을 실무에 활용하기 위한 기본 과정입니다. 피로해석에 관련된 전반적인 내용과 nCode DesignLife를 이용한 각각의 피로해석 방법에 대한 포괄적인 내용이 포함됩니다. 또한, 피로해석 해석실무과정을 습득하시려는 기계/전기/전자분야 CAE 엔지니어 분들을 대상으로 합니다.

대상

  • 피로 해석에 관심있는 기계/전기/전자분야 CAE Engineer.
SUBSCRIBER LOG IN
Subscribe Now

Learning Outcome

Following completion of this course, you will be able to:

  • Apply the stress-life analysis approach to predict the fatigue life of structures that deform in the linear material range.
  • Apply powerful material mapping, load mapping, and duty cycle techniques to create accurate and realistic models of complicated fatigue scenarios.
  • Apply the strain-life analysis approach to predict the fatigue life of structures that deform in the nonlinear material range.





 Available Dates

Learning Options

Training materials for this course are available with a Ansys Learning Hub Subscription. If there is no active public schedule available, private training can be arranged. Please contact us.

Agenda

This is a 1.5-day classroom course covering both tutorials and workshops. For virtual training, this course is covered over 3 x 2 hour sessions, lectures only.

Virtual Classroom Session 1

  • Lecture: Overview
  • Lecture: Introduction to CAE Fatigue
  • Lecture: Ansys Workbench / DesignLife Integration
  • Workshop: DesignLife Integration with Workbench
  • Workshop: Ansys nCode DesignLife Analysis Using Stress Life

Virtual Classroom Session 2

  • Lecture: DesignLife Interface
  • Lecture: Importing FE Results into DesignLife
  • Lecture: Material Mapping
  • Lecture: Load Mapping
  • Lecture: Duty Cycles
  • Workshop: Controlling FE Import
  • Workshop: Modifying Material Properties
  • Workshop: Time Series Load Mapping
  • Workshop: Time Step Load Mapping
  • Workshop: Duty Cycles

Virtual Classroom Session 3

  • Lecture: Stress Life Method
  • Lecture: Strain Life Method
  • Workshop: Stress Life Fatigue Solution
  • Workshop: Strain Life fatigue Solution Using Linear FE Results
  • Workshop: Strain Life fatigue Solution Using Nonlinear FE Results
Topics Covered
  • Introduction to CAE fatigue
  • Integration of Ansys nCode DesignLife and Workbench
  • DesignLife User Interface
  • Load Mapping
  • Stress Life and Strain Life methods of fatigue assessment
