Ansys Nuhertz FilterSolutions
RF filter design

Automated RF, microwave and digital filter design, synthesis and optimization in an efficient, straightforward process.



Automatic Filter Design Software

Ansys Nuhertz FilterSolutions provides automated RF, microwave and digital filter design, synthesis and optimization in an efficient, straightforward process. FilterSolutions starts with your filter performance specifications, synthesizes both lumped component and physical filter layout realizations, and automatically sets up filter analysis and optimization in the Ansys HFSS electromagnetic simulator.

  • check-icon-outline.png
    Lumped filters
  • check-icon-outline.png
    Digital filters
  • check-icon-outline.png
    IC-based filters
  • check-icon-outline.png
    Distributed (transmission line filters)
  • check-icon-outline.png
    Zero-indicator analog filters
Filter Design

Quick Specs

FilterSolutions provides performance specifications for every step from layout  to EM optimization

  • Embedded component databases
  • Planar filter realizations
  • Automatic filter synthesis
  • Widest range of filter topologies
  • HFSS integration
  • Distributed filter layout synthesis

What's New

2021 R2 release introduces an automated RF, microwave and digital filter design, synthesis, and optimization software. To learn more about Nuhertz FilterSolutions, register for this webinar


Automated Microwave Filter Design and Layout Synthesis

Quickly synthesize microwave filter designs and translate them directly to filter layout for your layout technology and substrate.


Integration to Ansys HFSS for Filter Design Validation and Optimization

Push designs directly to HFSS for design validation and electromagnetic optimization. Evaluate and correct for all cross-coupling, packaging, shielding and coupling effects with HFSS.


FilterQuick Interface Provides Easy Filter Design for Novice Users

Designing filters doesn’t have to be the domain of subject experts. Shift into the FilterQuick mode to design and synthesize a filter quickly and easily in a single panel. Push designs to HFSS for validation.

Capabilities

Designing high-performance microwave and mm-wave filters usually requires expert knowledge to synthesize filter layouts. A good CAE approach can create tuning-free designs that work within manufacturing or material tolerances. Creating an accurate first design prototype is essential to fast design optimization.



Key Features

One of a kind solution that offers quick, easy and automatic synthesis of a filter that meets your performance requirements.

  • Useful for Novices and Filter Experts Alike
  • Lumped (Passive) Filter Module
  • Distributed Filter Module
  • Active Filter module
  • Switched-Capacitor Filter module
  • Digital Filter module
  • Zmatch module
  • Filter Types available (Lumped and Distributed Filters)
  • Distributed Filter Design Topologies
  • Active Filter Implementations
  • IIR Digital Filter Designs Based on the Following Digital Transformations

Dual user interfaces are available for simple or detailed expert filter design. If you don’t have a deep filter background, the FilterQuick interface helps you to quickly design and synthesize common filter topologies. For experts, the Filter Advanced interface provides capabilities like advanced filter shaping, pole-zero location control, custom transfer function realization, duplexer/multiplexer design and more.

Synthesizes a lumped component filter (single or double-termination) of a selected filter topology to realize  your specified performance characteristics. Standard-value components may be applied, with standard (or non-standard) tolerance values for Monte-Carlo analysis. Components have ideal or finite Q, or may be based upon vendor component library models.

The Distributed Filter module synthesizes planar filter layouts on physics-accurate materials, incorporating transmission lines, vias and hybrid lumped elements. Filter layouts can performed for a variety of substrate formats, including microstrip, suspended substrate and stripline. Physical layouts (including metallization and substrate material properties) carried out quickly and accurately. Filter layouts are fully parameterized and may be seamlessly transferred to Ansys HFSS for immediate EM analysis; all geometries, materials, ports and analysis setups are automatically created. HFSS designs are fully parameterized and optimization setups are provided so you can proceed directly to design optimization to achieve filter response goals.

Some filter designs call for elimination of inductors, and active filter designs with OpAmps can sometimes be an attractive alternative. The FilterSolutions Active Filter module synthesizes filters to meet user-specified performance requirements in a wide range of active filter topologies, such as Thomas, Akerberg-Mossberg, Sallen-Key, Multiple Feedback, Leapfrog, GICs and more. Incorporate OpAmp models from your favorite vendor and include finite Q effects in your active filter designs.

Switched-Capacitor filters are zero-inductor components used in semiconductor processes where capacitors and switching transistors occupy very small spaces compared to inductors and resistors. Switched-Capacitor filters may be used to as digital filters and involve sampling circuit topologies. The Switched-Capacitor Filter module can synthesize designs in IIR and FIR realizations, as well as Bilinear, Matched-Z, Step Invariant, Modified Impulse Invariant or custom Z-transform designs.

For digital signal processing (DSP) and sampled systems, FilterSolutions takes user-specified performance specifications and a desired digital filter topology and synthesizes coefficients to produce the filter. Digital transformations are provided to Bilinear, Impulse Invariant (IIR), Step Invariant, Matched-Z and Finite Impulse Response (FIR) approximations. Filter realizations are provided in the form of the discrete transfer function, filter tap/block coefficients or as C language source code ready for incorporation into a DSP code block.

Zmatch starts with complex load definitions and synthesizes a matching network for maximum power transfer. It includes both Discrete Frequency and Broadband Match modes. Optimal matching networks are provided in lumped, distributed and hybrid realizations.

Include Bessel, Butterworth, Chebyshev I and II, Elliptic, Gaussian, Delay, Hourglass, Legendre, Matched, Raised Cosine, Tubular, Zigzag, Coupled-Resonator, Low Pass, High Pass, Band Pass, Band Stop, Diplexer, Multi-band and Cross-Coupled Folded Resonator, and Linear Phase. FilterSolutions provides an extraordinarily wide variety of useful and unique filter shapes using precision synthesis methods.

Include Lumped Translation, Inductor Translation, Stepped Impedance, Shunt Stub Resonators, Open Stub Resonators, Spaced Stubs, Dual Resonators, Spaced Dual Resonators, Parallel Edge Coupled, Hairpin, Miniature Hairpin, Ring Resonator, Interdigital and Combline. Synthesis is possible into planar components involving microstrip and inverted microstrip, stripline, symmetric and asymmetric stripline.

Include Thomas 1 and 2, Sallen & Key, Parallel, Akerberg, Multiple Feedback (MFB), GIC Biquad, GIC Ladder and  Leap Frog.

Bilinear, Impulse Invariant (IIR), Matched Z, Step Invariant, FIR Approximation. FIR Filter Types: Rectangular, Bartlett, Hanning, Hamming, Blackman, Blackman-Harris, Kaiser, Dolph-Cheby, Remez, Raised Cosine, Root Raised Cosine, Cosine Filter, Sine Filter, Matched Filter and Delay Filter.

Blogs

Faster Filter Design With Nuhertz FilterSolutions

Ansys Nuhertz FilterSolutions dramatically speeds up the design of lumped element (surface mount) and planar filters. It also includes synthesis tools for active, switched capacitor and digital filters. The netlist of active filters can be exported in SPICE format. The digital filter synthesis module can export C-code for the generated filter.

Together with SynMatrix tool, and other unique 3D electromagnetic simulation technologies in HFSS, such as analytical derivatives and automatic adaptive meshing, these two filter solutions are making RF and microwave filter design a much smoother process that is accessible to more engineers.
