June 25, 2019
Traditionally, engineers spend a lot of time on geometry meshing. The new workflow accelerates this process and greatly improves the user experience as a result.
In a recent release, Ansys introduced a task-based workflow that sped up Fluent meshing of watertight geometries by 70% — and with 50% fewer clicks.
However, some of the most important and complex CFD simulations contain dirty, non-watertight geometries. For instance, the geometry used in simulations of automotive front-end airflows, external aerodynamics and complex external/internal flows can’t be meshed using the task-based workflow. As a result, these geometries require extensive cleanup before simulation.
To overcome this obstacle, Ansys 2019 R2 offers a new Fluent meshing workflow that wraps dirty geometry without cleanup.
The fault-tolerant workflow improves Fluent meshing with wrapping. The workflow enables users with minimal experience to generate meshes of complex geometries.
For example, the workflow for external aerodynamics meshing has predefined settings based on best practices.
These settings help users create:
The workflow for non-watertight geometry offers distinct advantages over other meshing technologies.
The new Fluent meshing workflow is a significant timesaver. Overall, benchmarks indicate that an engineer experienced with Fluent will see a 2X speedup. The workflow virtually eliminates scripts, manual interventions or pop-ups —making it more accessible and easier to learn.
To learn more, visit the Fluent product page or watch the demo below.
Watch the fault tolerant workflow in action in this video. Cyclist geometry provided courtesy of Centre for Sports Engineering Research, Sheffield Hallam University.
