Vehicle Electrical System Design Tools
Reliable, durable, integrated and connected vehicle electrical system design with simulation
ANSYS APPLICATIONS
Optimizing Vehicle Electrical Systems with Simulation
Electrical systems underpin the more connected, electric and autonomous transportation and mobility vehicles of the future. They must operate reliably and safely across a wide range of harsh operating environments and be designed to fit in ever-smaller form factors, with reduced power requirements and lower weight. Optimizing electrical system design with simulation is the only way to deliver the vehicles of the future.
-
Wiring and Connectors
-
Infotainment
-
ADAS Systems and Sensors
-
Electric Vehicles
-
Antennas
-
Electrical Reliability
Featured Products
用於設計高頻和高速電子元件的 3D 電磁場求解器。其 FEM、IE、漸近和混合求解器可解決 RF、微波、IC、PCB 和 EMI 問題。
- 解決多層封裝
- 適用於 PCB 和封裝的 3D 配置工作流程
- 高頻電磁求解器
- 透過 3D 元件的 IP 保護
想解決多樣的結構分析需求，需要一套有限元分析 (FEA) 方案，該解決方案提供針對結構和耦合場行為的深入分析。
- 使用便利的多用途工具
- 一貫、可靠的求解器技術
- 動態的整合平台
此種前期設計工具會計算應力和應變，然後累積重複加載造成的損壞，使用有限元素分析確定產品的預測壽命。
- 完全整合於 Ansys Workbench 環境中
- 完整的材料庫可協助快速建置模型
- 提早在建置第一個原型之前，預測產品預期用途的最佳化能力
適用於電機和機電設備的電磁場模擬求解器。求解靜態、頻域和時變電場。
- 2D 和 3D 電磁 FEA
- 元件到系統 - 降階建模
- 進階電磁材料
- 自適應網格
- 多重物理量分析
- 分數模型模擬技術
Vehicle Electronics Success Through Simulation
Wiring and Connectors
Increasing the amount of cables leads to the potential for cross talk and interference. Designing effective shielding, routing and placement is critical. Simulation enables the determination of induced voltages and currents, radiated fields and shielding effectiveness with a streamlined cable workflow for even the most complex structures.
ADAS Systems and Sensors
Explore Ansys comprehensive solutions for ADAS and autonomous systems.
Antennas
Simulation proves critical to the design of the antenna—and for ensuring performance when integrated on the vehicle through interactions with the surrounding, electrically large environment.
Infotainment
Ansys provides electronics simulation solutions that span from the chip to the package to the system and the human machine interface.
Electric Vehicles
Experience the array of Ansys comprehensive solutions for electric vehicles.
Electronics Reliability
Electronics reliability simulation helps tackle the complex wealth of automotive electronics. Solve the increasing challenges as you ensure reliability and durability.
“By simulating SPEKTRA’s phased array antenna and printed circuit board-type feed network, Metawave predicted the behavior of the beam at all angles and pushed the boundaries of radar specifications.”
