White Paper

Simulation Workflow for Efficiency Calculation of a High-Performance Electric Powertrain

The powertrain’s efficiency significantly impacts driving range and performance in battery-electric vehicles. As the overall efficiency of the electric powertrain is typically more than 90%, further optimization is challenging. Especially in high-performance electric vehicles, the efficiency over one or multiple laps on a racing track is crucial. It requires an accurate estimation of power losses in each component of the powertrain and the analysis of the interaction between components under different operating conditions, such as temperature, speed/torque load point, and battery state of charge (SOC). Thus, optimizing component efficiency differs from optimizing the powertrain’s overall efficiency.

This white paper describes a system-level modeling approach for the powertrain that includes characterization of the inverter and electric machine and combines these models in a system-level drive cycle simulation to predict overall drive cycle efficiency.

This workflow was developed as part of the partnership between Ansys and the TAG Heuer Porsche Formula E Team to maximize powertrain efficiency of Porsche’s first fully electric race car — the Porsche 99X Electric.

Porsche Berlin Pit Row

Berlin E-Prix 2021 – TAG Heuer Porsche Formula E Team
