Acoustic Vehicle Alerting Systems (AVAS) for EVs

Acoustic vehicle alerting systems (AVAS) are sound generators used in EVs to alert pedestrians, cyclists, children, and other road users that a car is present. Played via loudspeakers located beneath the bodywork, these sounds are coordinated with the vehicle's real-time data to provide external auditory information on the vehicle’s speed, direction, and distance. AVAS is an important system in all electric vehicles for several reasons:

• Pedestrian safety: AVAS reduces the risk of crosswalk and other roadway accidents by producing an audible warning sound, both in drive and reverse, that alerts pedestrians to an oncoming EV.
• Sound branding: In addition to the visual aesthetics of their cars, automotive manufacturers can create a unique sound for their electric vehicles to distinguish them from other companies and improve brand recognition.
• Regulation compliance: Many countries mandate the use of AVAS in electric vehicles to improve road safety. United Nations regulations governing quiet road transport vehicles were created in 2017.

What Do AVAS Regulations Include?

When sound regulations were first implemented for vehicles, it was to make cars quieter. But now, today’s noise standards are in place to ensure the sounds that EVs make are audible, recognizable, and relevant.

As of 2019, several nations require AVAS on all electric vehicles. While regulations vary by country and region, these mandates were created to ensure that AVAS technology meets standards for noise levels and distinguishability.

Most regulations require the vehicle to emit a continuous sound up to 20 km/h, with a volume and pitch that vary proportionally to its speed. This way, pedestrians have the feeling of how fast the car is moving just by hearing it.

For instance, UN Regulation No. 138 states that a vehicle equipped with an AVAS will not emit an overall sound level that is more than 75 dB(A). It also states that the AVAS sound frequency range will vary at least 0.8% per 1 km/h in the speed range from 5-20 km/h when driving in a forward direction.

How Are AVAS Sounds Created?

To create sounds for electric cars, automotive manufacturers enlist the expertise of sound designers. Working within the automaker’s objectives and regulatory parameters, they use musical instruments, props, digital effects, and sampled sounds to create a unique acoustic experience for the brand.

But what does a brand sound like? For some car makers, the ideal sound is natural and organic, like wind and water. Others want their EVs to sound strong and cinematic while other brands prefer their EVs share the signature rumble of their legacy gas-powered models.

Creating the ideal EV soundscape requires considering how sounds (both artificial and natural) may interact at different times. Are different driving events delivering simultaneous sound information to the driver? Do these sounds complement or mask each other? When should sounds be harmonic or dissonate? What sounds already have meaning assigned? For example, a spacecraft-sounding AVAS from Jaguar had to be redesigned when tests showed people looked up at the sky when they heard it.

To account for these complexities, sound designers use Ansys Sound to anticipate, test, optimize and validate active sound design for electric vehicles (ASDforEV). This allows them to start from a baseline set of sounds, then alter the sound properties (such as loudness, pitch, and timbre) to create new sounds. They can also explore how the laws of sound change according to driving parameters such as speed, RPM, pedal load, acceleration, and torque. By hearing the sounds played in real time through the vehicle’s audio system or inside driving simulators, sound designers not only create future soundscapes, but also know how they’ll perform in real driving conditions.

The AVAS sound examples above were created and recorded using Ansys Sound software.

In addition to AVAS sounds for pedestrians, ASDforEV makes it possible to assess and tune other types of sounds for driver and passengers played inside the vehicle:

• Speed acceleration feedback (SAF) sounds
• Internal combustion engine (ICE) sounds
• Advanced driver-assistance system (ADAS) sounds
• Human-machine interaction (HMI), ambiance, warning sounds

Request a demo on Ansys Sound’s ASDforEV module.

The Future of the Acoustic Vehicle Alerting System

AVAS started as a pedestrian warning system, an acoustic alert created to warn people that a moving car is nearby. But as a quickly crowding EV market pushes manufacturers to distinguish their brand and technology enables even greater audio artistry, acoustic vehicle alerting systems will continue to evolve — from the electric whir of spaceships and power lines to all-new acoustic experiences that will redefine how sound moves us.
