Getting Started with PyMAPDL: ASTM E8 Tensile Test Simulation
The purpose of this exercise is to get users started with PyMAPDL, a Python based interface for interacting with the APDL solver from Ansys Mechanical™ structural finite element analysis software. The exercise leads the user through a hands-on tensile test simulation based on the ASTM E8 standard.
The example demonstrates how Python can be used to script, automate, and visualize finite element simulations, making advanced engineering analysis more accessible and interactive. By integrating PyMAPDL with Python’s scientific libraries, users gain exposure to modern simulation workflows.
The included Read Me document covers details such as relevant Python libraries, recommended skill levels, and other useful information.
Learning Outcomes
- Perform end-to-end PyMAPDL simulation: preprocess, solve, and post-process.
- Build parametric geometry, compute and visualize results.
- Extract mesh metrics and user-defined results using scripting.
Applicable Courses for Use
- Intro to Materials
- Mechanics of Materials/Strength of Materials
- Finite Element Analysis (FEA/FEM)
Downloadable Content
- Read Me Getting Started Document
- “Getting_started_with_PyMAPDL.ipynb” & “Getting_started_with_PyMAPDL.py” files
