Ansys Viewer

Ansys Viewer enables you to visualize, interpret and compare Ansys simulation results without the original simulation software. It helps improve collaboration with colleagues and customers, and provides a way to quickly relay simulation intent and results to your extended design team. Any stakeholder can use the viewer to open Ansys Viewer (.avz) files that have been exported from Ansys CFX-Pre, CFD-Post, TurboGrid and Ansys Mechanical.

The viewer's simple yet powerful features make it easy to review, share and analyze design information, pinpoint issues, suggest improvements, get approvals and make optimal design decisions. Previous experience with Ansys simulation software is not required. With Ansys Viewer you can:

  • Zoom, pan and rotate in 3D
  • Create cross-sections
  • Explode a multi-part model
  • Highlight, show and hide individual parts
  • Annotate in 2D and 3D
  • Save and reload views
  • Play a sequence of images



You might be interested in

Incorporate Diffractive Optics and Metalenses into Macroscopic Optics
Blog

Incorporate Diffractive Optics and Metalenses into Macroscopic Optics

See how Ansys Zemax OpticStudio 2024 R1 delivers enhanced support for incorporating metalenses and DOEs into macroscopic optical modeling more easily.

Read More
How to Determine the Resolution of Diffraction-limited Imaging Systems
Blog

How to Determine the Resolution of Diffraction-limited Imaging Systems

Learn how to characterize the resolution of a diffraction-limited imaging system, such as a microscope, in many different ways using Ansys Zemax OpticStudio.

Read More
How Ansys Optics Software Enhances Automotive Lighting Design
Blog

How Ansys Optics Software Enhances Automotive Lighting Design

In the world of automotive design, where safety and innovation go hand in hand, learn how Ansys Optics products are truly shining a light on the future.

Read More

Once downloaded, extract the contents of the zip file to a temporary directory, run the self-installing setup.exe file and follow the instructions. Select the option to Install Ansys Products and skip the License Server configuration step by selecting the Check box to finish the installation.
